Gomelong is a professional manufactures of Three Phase Register Electricity Energy Meter. Our professional expertise in manufacturing Three Phase Register Electricity Energy Meter has been honed over the past 10+ years. Three Phase Register Electricity Energy Meter is according with the correlative standard, rules of the nation , has the function as high-accuracy, well stability, advanced technology and easy operation. The performance index of the Three Phase Register Electricity Energy Meter accord with the technical requirements of nation standard.
Three Phase Register Electricity Energy Meter,type three-phase four wire electronic multifunction Meter machine, is a new type of multi-function meter.Three Phase Register Electricity Energy Meter is according with the correlative standard, rules of the nation , has the function as high-accuracy, well stability, advanced technology and easy operation. The performance index of the Three Phase Register Electricity Energy Meter accord with the technical requirements of nation standard, such as GB/T 17215.321 -2008 Class I and 2 Static A.C Active Watt-hour Meter, GB/T 17215.322-2008 Class 0.2S and 0.5S Static A.C Reactive Watt-hour Meter, GB/T 17215.323-2008 Class 2 and 3 Static A.C Reactive Watt-hour Meter and DL/T 614-1 997 Multi-function Watt-hour Meter the communication agreement accord with DL/T 645-1 997.
Features of Three Phase Register Electricity Energy Meter
1. Bidirectional measurement
2. Indication: power, reverse current, phase failure
Technical Parameters of Three Phase Register Electricity Energy Meter
|
Specification |
DTS5558L |
DTS5558R |
|
|
Accuracy |
Active |
Class1.0 |
Class1.0 |
|
Reactive |
Optional |
Optional |
|
|
Voltage |
Rated |
3x57.7/100V,3x220/380V |
3x57.7/100V,3x220/380V |
|
3x230/400V,3x240/415V |
3x230/400V,3x240/415V |
||
|
Range |
0.9Un~1.1Un |
0.9Un~1.1Un |
|
|
Limit |
0.8Un~1.2Un |
0.8Un~1.2Un |
|
|
Frequency |
|
50/60Hz |
50/60Hz |
|
Current |
Range |
1.5(6), 5(30), 10(50), 15(90), 20(100), 5(40), 5(100)A |
1.5(6), 5(30), 10(50), 15(90), 20(100), 5(40), 5(100)A |
|
Starting Current |
|
0.4%Ib |
0.4%Ib |
|
Constant |
Active |
400imp/kWh |
400imp/kWh |
|
Reactive |
Optional |
Optional |
|
|
Display |
Type |
LCD |
Register |
|
Digit |
6+1 |
6+1 |
|
|
Power Consumption |
Voltage Circuit |
≤0.8W,10VA |
≤0.8W,10VA |
|
Current Circuit |
≤4VA |
≤4VA |
|
|
Communication |
Interface |
Optical/Infrared/RS485 (Optional) |
Optical/Infrared/RS485 (Optional) |
|
Protocol |
MODBUS,DLT/645,IEC1107 |
MODBUS,DLT/645,IEC1107 |
|
|
Temperature |
Working Temperature |
-45℃~+55℃ |
-45℃~+55℃ |
|
Storage Temperature |
-40℃~+70℃ |
-40℃~+70℃ |
|
|
Humidity |
|
≤90% |
≤90% |
|
Protection |
|
IP54 |
IP54 |
